Суич, тип | Fixed Port |
Общ брой портове | 28 |
Основни портове, тип | 24x 10/100/1000Base-T |
Power Over Ethernet (PoE) | - |
Uplink портове | 4xSFP |
Свободни (10GB) слотове | - |
Управление | Cisco Business Dashboard; Cisco Business mobile app; Cisco Network Plug and Play (PnP) agent; Web user interface; SNMP; MIB; RMON; RSPAN; sFlow agent; DHCP; SCP; Other: Traceroute, single IP management, HTTP/HTTPS, SSH, RADIUS and etc. |
Stackable | - |
Fans | Fanless |
Захранване | 100-240V 50-60 Hz, internal, universal |
Routing | Dynamic Layer 3 routing |
Памет (Flash, RAM) | 512 MB (Flash), 1 GB DDR4 (DRAM), 1.5 MB (Packet buffer) |
Капацитет за маршрутизиране/превключване, Gbps | 56 Gbps |
Пропускателна способност, Mpps | 41.66 Mpps |
MAC адреси | 16 000 addresses |
VLAN (брой, стандарти) | Support for up to 4093 VLANs simultaneously; Port-based and 802.1Q tag-based VLANs, MAC-based VLAN, protocol-based VLAN, IP subnet-based VLAN; Management VLAN; Private/Guest/unauthenticated/Auto surveillance/CPE/Voice/Dynamic/Multicast TV VLAN |
QoS | 8 hardware queues; Strict priority and WRR; Port-based, 802.1p VLAN priority-based, IPv4/v6 IP precedence/Type of Service (ToS)/DSCP-based, Differentiated Services (DiffServ), classification and remarking ACLs, trusted QoS Queue assignment based on DSCP |
L2 мрежови стандарти | IEEE 802.3, IEEE 802.3u/ab/ad/z/x/af/at; IEEE 802.1D (STP)/1Q/p VLAN/w RSTP/s Multiple STP/X Port Access Authentication; RFC |
IPv6 functionality | IPv6 host mode, IPv6 over Ethernet, dual IPv6/IPv4 stack; IPv6 neighbor and router discovery (ND); DAD, ICMP; DHCPv6; IPv6 over IPv4 network with ISATAP tunnel support; IPv6 QoS; ACL; First Hop Security; MLD |
Сигурност | SSH, SSL, IEEE 802.1x (authenticator role):RADIUS authentication and accounting, MD5 hash, guest VLAN, unauthenticated VLAN, single/multiple host mode, and single/multiple sessions; MAC/Web-based authentication; STP; DHCP; IPSG; DAI; IPMB; SCT; SSD; ACLs |
Размери (Ш, Д, В), mm | 445 x 240 x 44 mm |
Опция за монтаж | Rackmount |
