Характеристики
| Интерфейс | 4× 10G SFP+ Slots |
| L3 Switching Features | Max 1,024, IPv6: Max 512 |
| Quality of Service | Voice VLAN |
| + Подарък | N |
| VLAN | Voice VLAN |
| L3 Switching Features | Relayed Interface |
| L2 Switching Features | 802.3x Flow Control |
| L3 Switching Features | VRRP: Version v2/v3, Max 64 groups |
| Гаранция | 60 месеца |
| L2 Switching Features | Multicast Filtering |
| L3 Switching Features | Dynamic ARP: 7,680 dynamic entries |
| Филтър Swich - PoE, SFP | PoE+ |
| Експлоатационни качества | Table of MAC addresses 32 K |
| Експлоатационни качества | Stacking Number: 4 |
| Експлоатационни качества | Stack Bandwidth: 20 Gbps Per Port (Full-Duplex) |
| Експлоатационни качества | Packet Buffer Memory 3MB |
| Интерфейс | 1× USB Type-C Console Port |
| Ethernet портове | 4× 10G SFP+ Slots |
| Интерфейс | 2× USB 2.0 Ports |
| L2 Switching Features | MAC Address Table |
| L2 Switching Features | Multicast VLAN Registration (MVR) |
| Quality of Service | Class of Service |
| L2 Switching Features | Port-based and VLAN-based Loopback Detection |
| L3 Switching Features | IPv4: Max 256, IPv6: Max 256 |
| L2 Switching Features | PIM-DM, PIM-SM (IPv4) |
| L2 Switching Features | ERPS |
| L2 Switching Features | RSPAN |
| VLAN | Multicast VLAN |
| L3 Switching Features | Relayed VLAN |
| L3 Switching Features | OSPF: Version v2/v3; v2: Max 8,190, v3: Max 4,097 |
| Brand | TP-LINK |
| Ethernet портове | 1× RJ45 Management Port |
| L2 Switching Features | MLD Snooping |
| L2 Switching Features | Static Multicast IP |
| L2 Switching Features | L2 Multicast Table |
| Работна температура | -5 °C to 50 °C (23 °F to 122 °F) @ 300 meters |
| L3 Switching Features | RIP: Version v1/v2, Max 8,190 |
| Quality of Service | User-Defined OUI |
| Софтуерни функции | L3 Features |
| L2 Switching Features | Supports 2,048 IGMP groups |
| L3 Switching Features | DHCP Server/Relay |
| VLAN | VLAN VPN (QinQ): Max 256 entries |
| VLAN | Max. 4K VLAN Groups |
| L2 Switching Features | Static Link Aggregation |
| Захранване | wo Field-replaceable and Hot-swappable Power Supply Modules** (100–240 VAC, 50/60 Hz) |
| Quality of Service | Bandwidth Control |
| Вид на монтаж | Rackmount |
| Работна температура | -5 °C to 40 °C (23 °F to 104 °F) @ 3,000 meters |
| VLAN | VLAN VPN (QinQ) |
| VLAN | Management VLAN |
| L2 Switching Features | IGMP Snooping |
| L2 Switching Features | Spanning Tree Protocol |
| L3 Switching Features | Proxy ARP |
| L3 Switching Features | Max 1,000 Manual Binding Entries |
| L2 Switching Features | Multicast |
| Размери дълбочина | 380 mm |
| Влажност на съхранение | 10%~90% без кондензация |
| VLAN | Protocol VLAN: Protocol Template 16, Protocol VLAN 12 entries |
| VLAN | MAC VLAN Entries: 200 |
| Интерфейс | 1× RJ45 Management Port |
| Експлоатационни качества | Switching capacity 128 Gbps per Unit |
| Интерфейс | 24× 10/100/1000 Mbps PoE+ RJ45 Ports |
| Експлоатационни качества | Jumbo shot 9 KB |
| Ethernet портове | 24× 10/100/1000 Mbps PoE+ RJ45 Ports |
| Quality of Service | Smoother Performance |
| Размери ширина | 440 mm |
| Софтуерни функции | VLAN |
| VLAN | GVRP |
| Захранване | **Shipping with one PSM500-AC module by default, and another field-replaceable redundant power supply requires purchasing separately. |
| Експлоатационни качества | Stacking Port: 10G SFP+ Slot (all uplink ports can be used as stacking ports) |
| Критерии за валидност на гаранцията | Гаранционна карта/Сериен номер |
| L3 Switching Features | DHCP Server: |
| L2 Switching Features | Fast Leave |
| Работна влажност | 10%~90% без кондензация |
| Експлоатационни качества | Data packet transmission rate 95.2 Mpps |
| L3 Switching Features | IP Interfaces: |
| L3 Switching Features | Static ARP: 512 static entries |
| Наличност | Ограничена - под 10 бр. |
| L3 Switching Features | Host Route Table: Max 6,100 entries |
| VLAN | Private VLAN |
| L3 Switching Features | Max 64 IP Pools |
| VLAN | 802.1q Tagged VLAN |
| Интерфейс | 1× RJ45 Console Port |
| L3 Switching Features | Static Routing |
| Ethernet портове | 1× RJ45 Console Port |
| L3 Switching Features | ECMP: 256 entries, max 32 ECMP Nexthops per Destination |
| Размери височина | 44 mm |
| Quality of Service | Action for Flows |
| Работна температура | -5 °C to 45 °C (23 °F to 113 °F) @ 2,000 meters |
| Софтуерни функции | Advanced Features |
| Филтър Swich | 24 порта |
| Софтуерни функции | L2 and L2+ Features |
| Системни изисквания | Microsoft® Windows® 98SE, NT, 2000, XP, Vista™ or Windows 7/8/10/11, MAC® OS, NetWare®, UNIX® or Linux. |
| Софтуерни функции | Quality of Service |
| Софтуерни функции | Security |
